Gel Documentation Systems
Specifications
Excellent optics coupled to a high quality camera, the gel. The LUMINAX gel documentation system is a high-performance fluorescent and colorimeter bio-imaging system. It features an 18 megapixel digital camera that connects to a PC via USB. The unit includes a light-tight cabinet with a UV safety switch and a roll-out transilluminator. Ultraviolet transilluminator provided in 312 & 365 nm dual ranges. Filter size of transilluminator is 210x260mm. Epi white light illumination from above is standard. The system is suitable for diagnostic labs, Biotech start-ups, DNA/protein research, and academic labs.
Camera Features
| 18 Megapixels Digital SLR Camera (DSLR) |
| 8 GB Memory Card storage and 24 Bit RGB |
| Zoom Lense 18-55 mm and another Zoom Lenses 55-250mm |
| EtBr 590 Filter |
| 312nm / 365nm UV |
| Operates camera directly and also via P.C. (i.e, Live on computer) |
| 7.7cm/3 LCD Hybrid CMOS Auto Focus |
| Wireless Remote control shooting of pictures directly from camera also Image storing card |
| Options:- Fixed LCD Screen and Tilt Rotatable Screen |
Dark Room Cabinet Features
- Dark room cabinet having removable UV Transilluminator with UV safety cover
- Dark room cabinet (Gel Documentation hood have dark black finishing inside). It have special port for U.V. Transilluminator which can easily come out from cabinet
- It have built in 2 white lights which works as E-pi-Illuminator
- Built in device having the camera at top and base fitted with rubber feet
Software Features
| Gel capture software comes as standard accessories with digital camera |
| Complimentary C.D. of gel analysis software download from internet through special technique |
| Complimentary C.D. of TUTOR software download from internet through special technique |
Advantages
- Easy to use, Low cost, yet high quality images
- High Grade auto focus DSLR Camera that can be Mounted conveniently
- Easy access to Transilluminator
- Transilluminator can come out as fitted in drawer
U.V. Gel Transilluminator Model: UV-302/365 is supplied with this system.
