Micro Refrigerated Centrifuge 20000 Rpm, Brushless Motor (-20°C)
Specifications
- Bench Top high speed Refrigerated Micro Centrifuge Machine
- Heavy duty C.R.C. construction finished with powder coating
- Stainless Steel centrifugal bowl for extra protection and easy cleaning.
- Fitted with well balanced brushless motor with electronic drive.
- 4 lines, 20 characters. LCD Display for set time, run time, set and run rpm, rcf and rotor identification.
- Digital Timer 0-99 minutes, lid lock and fast spin option
- Dynamic brake (automatic) and imbalance detector are provided.
- Selection of 3 acceleration + 4 deceleration profile.
- Microprocessor based. Programmable Speed Regulator from 2000 to 20000 in interval of 100 rpm
- Last test parameter recall and displays automatically on LCD
- P.I.D. Electronic digital temperature controller cum indicator is fitted to control the centrifuge temp. from room temp. upto -20°C means shuts off the cooling compressor within accuracy of + 2°C.
- Supply completed with, instruction manual, cord & plug to work on 220 volts 50Hz A.C.
Technical Parameter
| Max. Speed | 20000 R.P.M. |
| Max. RCF | 23000xg |
| Timer | 0-99 Min. |
| Motor | Brushless Motor |
| Temp. Range | from room temperature to -20°C |
| Temp. Accuracy | ±2°C (at 20000 rpm upto 5 minute operation of centrifuge) |
| Power | AC 220V 50 Hz 20A |
| Weight | 55 kg. Approx. |
| Dimension | L-25″ x W-20″ x H-14″ approx. |
Machine comes without rotor heads. Optional rotors can be selected as per customer’s requirements are as under:
| Rotor Type | Rotor Capacity | Speed on Rotor (RPM) | R.C.F. |
|---|---|---|---|
| Angle Rotor | 12 x 1.5/2.2 ml. | 20000 | 23000 xg |
| Angle Rotor | 24 x 1.5/2.2 ml. | 16000 | 18000 xg |
Note: The speed of the machine depends upon the type of rotor being used. If rotor is heavy the speed will reduce as per above
